JVC TD-V541 Stereo Cassette Deck

This JVC TD-V541 is a stereo cassette deck with Dolby B/C and HX-Pro noise reduction, it was first sold by JVC in 1991 with a recommended retail price of USD $380.

The main features of the JVC TD-V541 cassette deck are: 3 heads and no off-tape monitoring to save production cost, digital tape counter with 3 digits, tape type selection and capable of handling normal, chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the JVC TD-V541 cassette deck are generic digital peak reading meters with multi-color indication to provide visual saturation level of tape. Full-logic transport controls used on the JVC TD-V541 let it respond to the slightest finger contact for fast and effortless transport function selection.

Dolby C-type used in the JVC TD-V541 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The Dolby HX PRO system provides precise bias control during recording to reduce distortion and improve linearity in the high-frequency range, the result is recorded sound that is highly faithful to the original.

For undisturbed listening a jack connector for a pair of stereo headphones is supplied.
