Marantz SD2020U
The main features of the Marantz SD2020 cassette deck are: 2 heads, mechanical 3 digit tape counter, tape type selection and capable of handling normal, chrome and metal tapes, belt driven single-capstan transport.
Typical front loading cassette deck with the cassette compartiment located on the left side of the deck.
Dolby C-type used in the Marantz SD2020 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The Dolby HX PRO system provides precise bias control during recording to reduce distortion and improve linearity in the high-frequency range, the result is recorded sound that is highly faithful to the original.
To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.
2 Mono Microphone Inputs
RCA Input/Output Connectors
Headphones
3-Digıt Mechanical Counter
Record Protection
Silver Finish
Orientation Left
Front Loading
Stereo
2 Head Desiǥn
4 Track / 2 Channel
Dolby-B Noise Reduction
Dolby-C Noise Reduction
Dolby HX Pro®
Alternating Current
Individual Input Level Controls
1⅞ ips - 4.76 cm/s
Normal Tape Capabilıty
Chrome Tape Capabilıty
Metal Tape Capabilıty
Auto Reverse
Horizontal Tape Transport
Sìngle Capsŧan Transport
Belt Drive (Capsŧan)
Auto Stop
