Marantz SD5010 Stereo Cassette Deck
This Marantz SD5010 is a stereo cassette deck with Dolby B noise reduction, it was first sold by Marantz in 1981 with a manufacturer suggested retail price of USD $375.
The main features of the Marantz SD5010 cassette deck are: 2 heads, mechanical 3 digit tape counter, manual tape type selection and capable of handling normal, chrome, ferro-chrome and metal tapes, belt driven single-capstan transport.
Typical front loading cassette deck with the cassette compartiment located on the left side of the deck.
Level meters used on the Marantz SD5010 cassette deck are generic digital peak reading meters. Full-logic transport controls used on the Marantz SD5010 let it respond to the slightest finger contact for fast and effortless transport function selection.
The Dolby-B system reduces tape hiss on tapes recorded on the Marantz SD5010 by as much as 10 dB at the highest frequencies.
To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied.
- Linear Skating Mechanism
Historic events
Features of Marantz SD5010
Bias Fine Tune
2 Mono Microphone Inputs
Headphones
3-Digıt Mechanical Counter
Digital Peak-Reading Meters
Orientation Left
Champagne Finish
Front Loading
Gold Finish
Stereo
2 Head Desiǥn
4 Track / 2 Channel
Dolby-B Noise Reduction
Mechanical Transport Control
Full Logic Transport Control
Record Mute
Alternating Current
Individual Input Level Controls
1⅞ ips - 4.76 cm/s
Normal Tape Capabilıty
Manual Tape Type Selection
Ferro-Chrome Tape Capabilıty
Chrome Tape Capabilıty
Metal Tape Capabilıty
Horizontal Tape Transport
Auto Shutoff
Sìngle Capsŧan Transport
Belt Drive (Capsŧan)
