Philips F6622 Cassette Deck

This Philips F6622 is a stereo cassette deck with Dolby B and C noise reduction, it was first sold by Philips in 1983.

The main features of the Philips F6622 cassette deck are: 2 heads, mechanical 3 digit tape counter, tape type selection and capable of handling normal, chrome and metal tapes.

Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Philips F6622 cassette deck are generic digital peak reading meters. Full-logic transport controls used on the Philips F6622 let it respond to the slightest finger contact for fast and effortless transport function selection.

Dolby C-type used in the Philips F6622 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the F6622 filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.

• Micro Computer
• ALD (Automatic Location Device)
• FSX Head
• Solenoid Control
