Realistic SCT-27 Stereo Cassette Tape Deck

This Realistic SCT-27 is a stereo cassette deck with Dolby B and C noise reduction, it was first sold by Realistic in 1982 with a manufacturer suggested retail price of USD $300 and discontinued 3 years later in 1985.

The main features of the Realistic SCT-27 cassette deck are: 2 heads, mechanical 3 digit tape counter, manual tape type selection and capable of handling normal, chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Realistic SCT-27 cassette deck are generic digital peak reading meters with peak hold for easy adjustment of optimum recording level. Full-logic transport controls used on the Realistic SCT-27 let it respond to the slightest finger contact for fast and effortless transport function selection.

Dolby C-type used in the Realistic SCT-27 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the SCT-27 filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.

• Solenoid Logic Controlled
