Sony TC-FX120 Stereo Cassette Deck

The Sony TC-FX120 is a stereo cassette deck with Dolby B and C noise reduction, it was introduced by Sony in 1990 and discontinued a year later.

The main features of the Sony TC-FX120 cassette deck are: 2 heads, analog 3 digit tape counter, manual tape type selection with support for normal, chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Sony TC-FX120 cassette deck are generic digital peak reading meters. Soft-touch controls for fast and easy transport function selection of the Sony TC-FX120 cassette deck.

Dolby C-type used in the Sony TC-FX120 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type.

For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.

• Auto Tape Selector
• High Density Head
• Peak Level Meter
• DC Servo Controlled Motor
• Low Distortion Direct Coupled Circuit
