Sony TC-FX500R Stereo Cassette Deck

This Sony TC-FX500R is a auto-reverse stereo cassette deck with Dolby B and C noise reduction, it was first sold by Sony in 1982 with a list price of USD $280 and discontinued a year later.

The main features of the Sony TC-FX500R cassette deck are: 2 heads, mechanical 3 digit tape counter, automatic tape type selection and capable of handling normal, chrome, ferro-chrome and metal tapes, belt driven auto reverse transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Sony TC-FX500R cassette deck are generic digital peak reading meters. Full-logic transport controls used on the Sony TC-FX500R let it respond to the slightest finger contact for fast and effortless transport function selection.

Dolby C-type used in the Sony TC-FX500R provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the TC-FX500R filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wired remote control.
