Sony TC-K8 Stereo Cassette Deck

This Sony TC-K8 is a stereo cassette deck with Dolby B noise reduction, it was first sold by Sony in 1976 with a manufacturer suggested retail price of USD $520 and discontinued 2 years later in 1978.

The main features of the Sony TC-K8 cassette deck are: 2 heads, mechanical 3 digit tape counter and memory stop, manual tape type selection and capable of handling normal, chrome and ferro-chrome tapes with additional manual equalization selection, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well which is opened by a damped mechanism. Additionally the compartement can be accessed easly for head cleaning by removing the well-cover.

Level meters used on the Sony TC-K8 cassette deck are optical digital peak reading meters with peak hold for easy adjustment of optimum recording level. Full-logic transport controls used on the Sony TC-K8 let it respond to the slightest finger contact for fast and effortless transport function selection.

The Dolby-B system reduces tape hiss on tapes recorded on the Sony TC-K8 by as much as 10 dB at the highest frequencies. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the TC-K8 filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wired remote control.

• Ferrite & Ferrite Head
• Two Motor
• Frequency Servo Control
• Auto Shut Off
