TEAC V-360C Stereo Cassette Deck

This TEAC V-360C is a stereo cassette deck with Dolby B and C noise reduction, it was first sold by TEAC in 1983 and discontinued a year later.

The main features of the TEAC V-360C cassette deck are: 2 heads, mechanical 3 digit tape counter, tape type selection and capable of handling normal, chrome and metal tapes.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the TEAC V-360C cassette deck are generic digital peak reading meters.

Dolby C-type used in the TEAC V-360C provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.
