Technics RS-M24
Dolby B NR Soft Touch Wired Remote Control Metal Tape

This Technics RS-M24 is a stereo cassette deck with Dolby B noise reduction, it was first sold by Technics in 1980 with a recommended retail price of USD $260 and discontinued a year later.

The main features of the Technics RS-M24 cassette deck are: 2 heads, mechanical 3 digit tape counter, manual tape type selection and capable of handling normal, chrome, ferro-chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Technics RS-M24 cassette deck are generic digital peak reading meters with peak hold for easy adjustment of optimum recording level. Soft-touch controls for fast and easy transport function selection of the Technics RS-M24 cassette deck. Cue and review can be used to easily and quickly locate the beginning of a passage.

The Dolby-B system reduces tape hiss on tapes recorded on the Technics RS-M24 by as much as 10 dB at the highest frequencies.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. All main transport commands can be issued remotely with a wired remote control.

Compact Cassette
  • Full Auto Stop
  • Rewind Auto Play

Historic events

1980 Dolby C Noise Reduction introduced by Dolby Laboratories.
1981 Dave Smith proposes the Universal Synthesizer Interface that would become the MIDI standard in 1983.

Features of Technics RS-M24

Connectors
Connectivity
2 Mono Microphone Inputs Headphones Wired Remote Control
Display
Display
3-Digıt Mechanical Counter Digital Peak-Reading Meters Peak Hold
Cassette Exterior
Exterior
Silver Finish Orientation Left Black Finish Front Loading
Compact Cassette
General
Stereo
Head Configuration
Head Configuration
2 Head Desiǥn 4 Track / 2 Channel
Noise Resuction
Noise Reduction
Dolby-B Noise Reduction
Controls
Operation
Cue / Review Auto-Play Timer Recording/Playback Soft Touch Transport Control Line / Mic Input Select Record Mute One-Touch Record/Pause
Power
Power Requirements
Alternating Current
Preamplifier
Preamplifier
Individual Input Level Controls
Tape Speed
Speed
1⅞ ips - 4.76 cm/s
Tape
Tape
Manual Tape Type Selection Ferro-Chrome Tape Capabilıty Normal Tape Capabilıty Chrome Tape Capabilıty Metal Tape Capabilıty
Transport
Transport
Auto Shutoff Mechanical Tape Loading Sìngle Capsŧan Transport Belt Drive (Capsŧan)
