Luxman K-03 Manual Calibration Cassette Deck

This Luxman K-03 is a stereo cassette deck with Dolby B and C noise reduction, it was first sold by Luxman in 1984 with a list price of USD $1,200 and discontinued 4 years later in 1988.

The main features of the Luxman K-03 cassette deck are: 3 heads and off-tape monitoring, digital linear tape counter with 4 digits, manual tape type selection and capable of handling normal, chrome and metal tapes, dual capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Luxman K-03 cassette deck are analog needle VU reading meters. Full-logic transport controls used on the Luxman K-03 let it respond to the slightest finger contact for fast and effortless transport function selection.

To ensure the best response from the wide variety of tapes available adjustment of, bias and sensitivity, to optimum levels can be performed prior to recording.

Dolby C-type used in the Luxman K-03 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. A Subsonic filter is provided in the Luxman K-03 to prevent infrasonic signals generated when playing a warped record. These signals can upset the Dolby system and prevening it from functioning properly. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the K-03 filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wired remote control.

• Closed Loop Dual Capstan
• Dual Capstan
• 3 Heads DD
