Tandberg TCD 3014 Cassette Deck

This Tandberg TCD 3014 is a stereo cassette deck with Dolby B and C noise reduction, it was first sold by Tandberg in 1982 with a recommended retail price of USD $1,395 and discontinued 3 years later in 1985.

The main features of the Tandberg TCD 3014 cassette deck are: 3 heads and off-tape monitoring, digital linear tape counter with 4 digits and memory stop, manual tape type selection and capable of handling normal, chrome and metal tapes, belt driven dual-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed directly over the head block. Additionally the heads can be easilly accessed for cleaning.

Level meters used on the Tandberg TCD 3014 cassette deck are analog needle VU reading meters. Full-logic transport controls used on the Tandberg TCD 3014 let it respond to the slightest finger contact for fast and effortless transport function selection. Cue and review can be used to easily and quickly locate the beginning of a passage.

Manual playback azimuth correction provides controls to manually adjust the azimuth of the TCD 3014s playback head to the azimuth the tape was recorded with so playback on the {0} is possible with the best sound quality. Record azimuth correction. To ensure the best response from the wide variety of tapes available adjustment of, bias and sensitivity, to optimum levels can be performed prior to recording.

Dolby C-type used in the Tandberg TCD 3014 provides 20 dB of noise reduction above about 1,000 Hz, fully doubling the amount given by B-type. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the TCD 3014 filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wireless remote control.

• 4 Motors
• 3 Heads
• Microprocessor Controlled
• Dyneq
• Actilinear Recording
