Technics RS-M260
Dolby B NR Soft Touch Wired Remote Control Metal Tape 3 Head

This Technics RS-M260 is a stereo cassette deck with double Dolby B noise reduction, it was first sold by Technics in 1980 with a list price of USD $380 and discontinued 3 years later in 1983.

The main features of the Technics RS-M260 cassette deck are: 3 heads and off-tape monitoring, digital tape counter with 3 digits, manual tape type selection and capable of handling normal, chrome, ferro-chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Technics RS-M260 cassette deck are generic digital peak reading meters. Soft-touch controls for fast and easy transport function selection of the Technics RS-M260 cassette deck. Cue and review can be used to easily and quickly locate the beginning of a passage.

The Dolby-B system reduces tape hiss on tapes recorded on the Technics RS-M260 by as much as 10 dB at the highest frequencies. The three-head configuration of the Technics RS-M260 requires a Double Dolby system, one for recording and one for playback.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wired remote control.

Compact Cassette
  • Full Auto Stop
  • SX Head (Sendust Extra)
  • Fluorescent Meter
  • Rewind Auto Play
  • 3 Head System

Historic events

1980 Dolby C Noise Reduction introduced by Dolby Laboratories.
1981 Dave Smith proposes the Universal Synthesizer Interface that would become the MIDI standard in 1983.
1982 Seiko introduced the world’s first TV watch.
1983 The Musical Instrument Digital Interface (MIDI) is introduced at the first North American Music Manufacturers (NAMM) show in Los Angeles.

Features of Technics RS-M260

Connectors
Connectivity
2 Mono Microphone Inputs RCA Input/Output Connectors Headphones Wired Remote Control
Display
Display
3-Digıt Digital Counter Digital Peak-Reading Meters
Cassette Exterior
Exterior
Silver Finish Orientation Left Black Finish Front Loading
Compact Cassette
General
Stereo
Head Configuration
Head Configuration
3 Head Desiǥn 4 Track / 2 Channel
Indicators
Indicators
Source/Tape Record
Noise Resuction
Noise Reduction
Dolby-B Noise Reduction Double Dolby NR Circuits
Controls
Operation
Cue / Review Timer Recording/Playback Line / Mic Input Select Soft Touch Transport Control Record Mute Real-Time Tape Monitoring
Power
Power Requirements
Alternating Current
Preamplifier
Preamplifier
Individual Input Level Controls Output-Level Control
Tape Speed
Speed
1⅞ ips - 4.76 cm/s
Tape
Tape
Manual Tape Type Selection Ferro-Chrome Tape Capabilıty Normal Tape Capabilıty Chrome Tape Capabilıty Metal Tape Capabilıty
Transport
Transport
Auto Shutoff Mechanical Tape Loading Sìngle Capsŧan Transport Belt Drive (Capsŧan)

Similar to Technics RS-M260 from the period 1980 - 1983
