Telefunken TC 650M HiFi Stereo Cassette Deck

The Telefunken TC 650M is a stereo cassette deck with Dolby B and High-Com noise reduction, it was introduced by Telefunken in 1980 and discontinued a year later.

The main features of the Telefunken TC 650M cassette deck are: 2 heads, analog 3 digit tape counter and memory stop, manual tape type selection with support for normal, chrome, ferro-chrome and metal tapes (automatic for normal and chrome tapes), belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the center of the deck. Tape eject is operated mechanically and the cassette needs to be placed with the side to be played facing forward in the cassette well.

Level meters used on the Telefunken TC 650M cassette deck are analog needle VU reading meters. Mechanical transport controls for reliable Telefunken TC 650M transport function selection. Cue and review can be used to easily and quickly locate the beginning of a passage.

The Dolby-B system reduces tape hiss on tapes recorded on the Telefunken TC 650M by as much as 10 dB at the highest frequencies. The High Com system (as used in the Telefunken TC 650M) works as a broadband 2:1:2 compander, achieving almost 15 dB of noise reduction for low and up to 20 dB for higher frequencies, while avoiding most of the acoustic problems observed with other high compression broadband companders. To further maintain recording accuracy, the TC 650M incorporates a switchable multiplex filter. When you record FM stereo broadcasts, the MPX filter of the TC 650M can be swiched on to prevent the standard 19kHz FM pilot signal from interfering with the noise reduction system.

To make live recordings this deck has 2 microphone inputs to connect a microphone with a DIN connector. For undisturbed listening a DIN connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable.
