Eumig FL-1000uP HiFi Stereo Three Head Cassette Deck

This Eumig FL-1000uP is a stereo cassette deck with Dolby B and High-Com noise reduction, it was first sold by Eumig in 1978 with a list price of USD $1,550 and discontinued 4 years later in 1982.

The main features of the Eumig FL-1000uP cassette deck are: 3 heads and off-tape monitoring, digital tape counter with 4 digits and memory stop, manual tape type selection and capable of handling normal, chrome and metal tapes, belt driven single-capstan transport.

Typical front loading cassette deck with the cassette compartiment located on the left side of the deck. Tape eject is operated mechanically and the cassette needs to be placed sideways in the cassette well.

Level meters used on the Eumig FL-1000uP cassette deck are generic digital peak reading meters. Full-logic transport controls used on the Eumig FL-1000uP let it respond to the slightest finger contact for fast and effortless transport function selection.

To ensure the best response from the wide variety of tapes available adjustment of, bias and sensitivity, to optimum levels can be performed prior to recording.

The Dolby-B system reduces tape hiss on tapes recorded on the Eumig FL-1000uP by as much as 10 dB at the highest frequencies. The High Com system (as used in the Eumig FL-1000uP) works as a broadband 2:1:2 compander, achieving almost 15 dB of noise reduction for low and up to 20 dB for higher frequencies, while avoiding most of the acoustic problems observed with other high compression broadband companders. The 19kHz multiplex pilot slgnal present in FM stereo broadcasts can cause false triggering of the noise reduction system. The switchable MPX filter of the FL-1000uP filters out the pilot signal, and assuring proper Dolby processing of FM stereo programs.

To make live recordings this deck has 2 microphone inputs to connect microphones with a jack connector. For undisturbed listening a jack connector for a pair of stereo headphones is supplied. Connection to other audio components for plaback can be achieved by a RCA cable and recording from a source by a RCA cable. All main transport commands can be issued remotely with a wired remote control.
